Ortofon SPU Classic N E - MC Element

Ortofon SPU Classic NE - MC Element

The SPU Classic NE provides the same sound reproduction properties as the SPU Classic GM E series, but is sold without the integrated headshell unit. The SPU Classic N is a Moving Coil (MC) cartridge with an elliptical stylus profile and provides more detailed sound reproduction and expansive imaging. Listeners who wish to mount the SPU Classic on a traditional headshell may do so, and those with vintage SPU-type headshells can use the Classic NE to recreate an authentic and functional SPU cartridge.

Specifications

- Output voltage at 1000 Hz, 5cm/sec. 200 µV

- Channel balance at 1 kHz < 1 dB

- Channel separation at 1 kHz > 20 dB

- Channel separation at 15 kHz > 10 dB

- Frequency range at - 3dB 20-25.000 Hz

- Frequency response 20-20.000 Hz + 3 / - 2 dB

- Tracking ability at 315Hz at recommended tracking force *) 65 µm

- Compliance, dynamic, lateral 8 µm/mN

- Stylus type Nude elliptical

- Stylus tip radius r/R 8/18 µm

- Tracking force range 3,0-5,0 g (30-50 mN)

- Tracking force, recommended 4,0 g (40 mN)

- Tracking angle 20°

- Internal impedance, DC resistance 6 Ohm

- Recommended load impedance > 10 Ohm

- Coilwire material High Purity Copper (OFC)

- Cartridge colour Black

*) Typical value
